6.5mm Banana Plug--65A

6.5mm Female Banana Socket

Industrial Grade | For Motor Controllers / ESCs / EVs

• Conductor: Brass Gold-Plated (0.03µm Plating)
• Current: 65A Continuous / 140A Instantaneous
• Resistance: 0.17 mΩ
• Voltage: 500V
• Wire Gauge: 8AWG
• Certifications: RoHS Compliant (Brass + Gold-Plated)
• Customizable: Packaging / OEM / ODM Supported

1.

2. 1.Basic Specifications

   Product Name: 6.5mm Female Banana Socket Terminal / YWBT6.5 Banana Plug

   Conductor Material: Brass, Gold-Plated (Plating Thickness: 0.03µm)

   Rated Voltage: 500V (Industrial Grade)

   Rated Continuous Current: 65A

   Instantaneous Current: 140A

   Contact Resistance: 0.17 mΩ

   Recommended Wire Gauge: 8AWG

   Type: Battery Terminal / Banana Connector

   Place of Origin: Guangdong, China

   Brand Name: YOUWEI

   Model Number: YWBT6.5
3.

4. 2.Key Performance Parameters

   Current-Carrying Capacity: 65A Continuous / 140A Instantaneous, Low Contact Resistance for Stable Power Transmission

   Electrical Safety: Rated 500V, Meets Basic Industrial Electrical Safety Requirements

   Surface Conductivity: Gold-Plated Finish, Reduces Oxidation, Ensures Long-Term Stable Contact

   Material Performance: Solid Brass Body with Good Conductivity and Corrosion Resistance
5.

6. 3.Structural Features

   Solid Brass Body: Durable, High Conductivity, Ideal for High-Current Applications

   Gold-Plated Contact Surface: 0.03µm Plating, Anti-Oxidation, Low Contact Resistance

   Female Socket Design: Compatible with Standard 6.5mm Banana Plugs, Easy Installation

   Compact Size: Small Form Factor for Space-Saving Integration in Controllers & Devices
7.

8. 4.Application Scope

   Widely Used for Motor Controllers, ESCs (Electronic Speed Controllers), Electric Vehicles, Agricultural Plant Protection Drones, Industrial Equipment, and Other High-Power Scenarios Requiring Reliable High-Current Connection.
9.

10. 5.Customization Options

    Custom Packaging

    Drawing-Based Customization, Sample-Based Customization Available

    OEM/ODM Service Supported

    Custom Order Quantity & Length (Packaging) Available
